一、Background introduction

TG vehicle networking monitoring platform is the vehicle monitoring and management system based on IOT technology in the independent research and development, through the installation of GPS vehicle tracker, real-time acquisition and upload vehicle data, through the wireless network operators to the vehicle data transmission system platform, and realize the vehicle information remote access, real-time positioning, anti-theft tracking, remote alarm and other functions, the realization of vehicle intelligent remote management.

The design scheme is as follows：

The private car vehicle installed on-board GPS device, through the mobile phone or APP platform can monitor the real-time dynamic vehicle, grasp the actual position of the vehicle at any time, query real-time vehicle positioning, users quickly grasp the position of the vehicle.

The installation of connecting vehicles ACC, their vehicle detection ACC status, ACC closed automatically into the fortified state, automatically shut down the fortified state ACC open.

Support rectangular, circular, polygonal shape electronic fence three, drawing on the map, and set the fence alarm rules, let the vehicle immediately alarm trigger fence.

The remote control (optional function and power relay), the platform can guarantee the safety of vehicles in the case of remote disconnect circuit or restore circuit circuit action on the specified vehicles, reduce vehicle theft and other dangerous accidents.

二、system composition

The management system is composed of intelligent burglar alarm terminal, relay, SIM card, management platform, mobile phone management software (APP).

IOT adapter：It is used to transmit the electric vehicle data to the TG vehicle management platform, so that users can remotely view the operation of the vehicle in the mobile phone APP and management platform.

Intelligent terminal：TG-303 is specially developed for the GPS positioning anti-theft device for vehicle, with a key and a key function of disarming fortification. Through the remote control of APP can be the power source of the vehicle in the vehicle is stolen, robbed, illegal mobile situation can remotely control the brakes, let the vehicle cannot be riding, support vehicle abnormal vibration, displacement alarm, wheeled alarm, any situation can realize positioning and tracking.

Management platform：The intelligent vehicle management platform provides users with information management, vehicle information management, equipment information management, vehicle positioning, sales statistics management, operation statistics management and system management functions. Users can use the platform for equipment binding, alarm settings, user settings, vehicle information, vehicle inquiries, location inquiries.

三、Vehicle monitoring platform

In a vehicle mounted intelligent terminal, users can install the TGTrack application software in the mobile phone, then you can track the real-time running state of the vehicle, the vehicle driving history can also track playback and analysis, when the outside of the vehicle battery is less than a preset value, will automatically switch the electric equipment enabled device built-in battery, to avoid the loss of the vehicle battery electricity, when the internal battery voltage is too low, low voltage alarm equipment will be issued, of course, when the electric displacement, speeding off, equipment vibration, ACC state changes are not normal circumstances, the user will receive from APP in the push of the alarm information, the user can timely protection of their vehicles, vehicle safety the effective protection.

Functional characteristics

1 、 real time positioning

The real-time position information and driving data information of the designated vehicle are displayed on the cloud platform in real time.

2, track playback

In order to reproduce the whole process of vehicle running, the track of the vehicle running at any time can be replayed on the platform electronic map at the same time, and the report forms can be exported.

3, alarm statistics

Cross platform alarm, overspeed alarm, low voltage alarm, fatigue alarm, anti demolition alarm and other platform alarm methods to ensure the safe driving of the vehicle.

4 mileage statistics

The high frequency positioning technology is designed to calculate the mileage in one second, and the center platform can accurately calculate the mileage of vehicles daily or monthly, and output the report forms.

5, fuel consumption statistics

According to the high precision mileage statistics data, plus the average fuel consumption data (background input), the system automatically calculates the theoretical fuel consumption and output the report. It effectively avoids the hidden danger caused by the oil sensor installed in the fuel tank of the original car, and ensures the safe driving of the vehicle.

6, remote control (optional function and power relay)

It can remotely disconnect the oil circuit or circuit or restore the circuit of the oil circuit in the case of ensuring the safety of the vehicle.

7, service period reminder (platform function)

The center platform can calculate the service period of all vehicles. When the vehicle service period is about to expire, the platform will be prompted one month ahead of time.

8, maintenance expiration reminder (platform function)

Set the fixed value of the vehicle maintenance time, when the vehicle use time is about to reach the set value, the central platform will be reminded one month ahead of schedule.

9. Driving record analysis (platform function)

The center platform can measure the mileage and time of the vehicle at a certain time, record the maximum vehicle speed, etc., and analyze the vehicle driving record intelligently.

10, mobile / platform car search

Through the mobile phone / computer whenever and wherever possible query vehicle location, track playback, streetscape, alarm status, provide APP software applications in the app store to download the TGTrack application can be installed, you can use mobile phone to monitor the operation of the vehicle, an account of scenes to use, simple and convenient.

11, a key to find cars

When the car parked in unfamiliar places, or forgot to stop where can not find, open the APP car chase mode, you can navigate to the car a key position.
